Capacidades (BTU)
• 9,000 • 12,000 • 18,000 • 24,000 •
Voltaje
• 208~230V, 60Hz, 1Ph •
Refrigerante
• R410A •
Garantía
• 1 año en piezas y 5 años del compresor •
Model No. AZLCI4C4S09 / AZLEM4C409 AZLCI4C4S12 / AZLEM4C412 AZLCI4C4S18 / AZLEM4C418 AZLCI4C4S24 / AZLEM4C424 Voltage, Frequency, Phase V 220V~,60Hz,1P 220V~,60Hz,1P 220V~,60Hz,1P 220V,60Hz,1P Cooling Capacity BTU/H 9000 12000 18000 22000 Rated Input-Cooling W 815 1085 1628 2170 Moisture Removal L/h 0.9 1.2 2 2.5 Air Circulation High m3/h 500 600 1000 1150 EER for Cooling W/W 3.24 3.24 3.24 3.24 Refrigerant R410A R410A R410A R410A Refrigerant charge volume oz 21.16 33.51 45.85 53.97 Indoor Unit Noise Level High(dB (A)) 39 40 44 48 Mid(dB (A)) 36 36 40 44 Low(dB (A)) 32 32 38 40 Outdoor Unit Noise Level dB (A) 52 54 56 56 Power Supply Rated Current Cooling (A) 3.9 5 7.4 9.2 Connecting Pipe Diameter Liquid Pipe inch 1/4 1/4 1/4 3/8 Gas Pipe inch 3/8 1/2 1/2 5/8 Dimensions Net Dimensions WxHxD (inch) Indoor Unit 31.26 x 10.95 x 8.58 33.98 x 10.82 x 8.62 38.11 x 12.99 x 9.64 45.2 x 12.4 x 9.13 Outdoor Unit 25.98 x 9.44 9.76 28.14 x 9.44 x 18.97 31.88 x 23.03 x 11.02 33.85 x 25.59 x 12.20 Net Weight (lbs) Indoor Unit 18.73 18.73 27.55 31.96 Outdoor Unit 50.7 58.42 81.57 105.82 Packing Dimensions WxHxD (inch) Indoor Unit 830?335?260 900X335X260 1040x390x315 1210?390?315 Outdoor Unit 780?315?530 830?315?530 940?630?385 995?420?720 Gross Weight (lbs) Indoor Unit 10 11 15 17 Outdoor Unit 25 29 40 52 Loading Capacity (20'/40'/40'HC ) 158/323/360 143/198/335 84/174/194 62/128/145 Application Area m2 9~18 12~24 19~32 27~45
