Aplicaciones Comerciales
VRF’S de Mitsubishi Heavy Industries son para usos comerciales.
Especificaciones
| Item | Unit | FDU650FKXZE1 | FDU1100FKXZE1 | FDU1800FKXZE1 | FDU2400FKXZE1 | |
|---|---|---|---|---|---|---|
| Nominal Cooling Capacity | kW | 9 | 14 | 22.4 | 28 | |
| Nominal Heating Capacity | kW | 6.5 | 10.5 | 16 | 21.5 | |
| Power Source | 1 Phase 220v, 60Hz | |||||
| Power Consumption | Cooling | kW | 0.24 | 0.35 | 1.16 | 1.16 |
| Heating | 0.24 | 0.35 | 1.16 | 1.16 | ||
| Sound Pressure Level | dB(A) | Hi: 31 | Hi: 37 | Hi: 42 | Hi: 45 | |
| Exterior Dimensions H x W x D | mm | 280x950x635 | 280x1370x740 | 379x1600x893 | ||
| Net Weight | kg | 34 | 54 | 89 | 89 | |
| Air Flow (Standard) | m3/min | Hi: 11 | Hi: 18 | Hi: 30 | Hi: 40 | |
| External Static Pressure | Pa | 200 (at Hi Air Flow) | ||||
| Air Filter, Qty | Procure Locally | |||||
| Remote Control (option) | wired: RC-EX3, RC-E5, RCH-E3 wireless: RCN-KIT4-E2 | |||||
| Refrigerant Piping Size | mm (in) | Liquid Line: ?9.52(3/8") Gas Line: ?15.88 (5/8") | Liquid Line: ?9.52(3/8") Gas Line: ?19.05 (3/4") | Liquid Line: ?9.52(3/8") Gas Line: ?22.22 (7/8") |
