Capacidades (BTU)
• 12,000 • 14,000 • 16,000 •
Voltage
• 208~230V, 60Hz, 1Ph •
Refrigerante
• R410A •
Garantía
• 1 año en piezas y 5 años del compresor •
| Model | CH4H6C12K | CH4H6C14K | CH4H6C16K | ||
|---|---|---|---|---|---|
| Capacity Range | HP | 4 | 5 | 6 | |
| Capacity | Cooling | kW | 12.1 | 14 | 16 |
| Heating | kW | 14 | 18.5 | 18.5 | |
| EER | kW/kW | 3.97 | 3.52 | 3.3 | |
| COP | kW/kW | 4.28 | 4.14 | 3.96 | |
| IPLV | Cooling | kW/kW | / | / | / |
| Power Supply | V/Ph/Hz | 220~240-1Ph-50Hz&208~230V-1Ph-60Hz | |||
| Max. Circuit/Fuse Current | A | 28.1/32 | 33/6/40 | ||
| Power Consumption | Cooling | kW | 3.05 | 4.85 | |
| Heating | kW | 3.27 | 4.67 | ||
| Maximum Drive Idu No. | unit | 7 | 9 | ||
| Refrigerant Charge Volume | kg | 5 | 5 | ||
| Sound Pressure Level | dB(A) | 55 | 58 | ||
| Connecting Pipe | Liquid | mm | 9.52 | ||
| Gas | mm | 15.87 | 19.05 | ||
| Dimension | Outline | mm | 900x340x1345 | ||
| (WxDxH) | Package | mm | 998x458x1514 | ||
| Net Weight/Gross Weight | kg | 110/120 | 110/120 | 110/120 | |
| Loading | 40' GP | set | 57 | 57 | 57 |
| Quantity | 40' HQ | set | 57 | 57 | 57 |
