Aplicaciones Comerciales
VRFs de Mitsubishi Heavy Industries son para usos comerciales.
Especificaciones
| Item | Unit | FDE36KXZE1 | FDE45KXZE1 | FDE56KXZE1 | FDE71KXZE1 | FDE112KXZE1 | FDE140KXZE1 | |
|---|---|---|---|---|---|---|---|---|
| Nominal Cooling Capacity | kW | 3.6 | 4.5 | 5.6 | 7.1 | 11.2 | 14 | |
| Nominal Heating Capacity | kW | 4 | 5 | 6.3 | 8 | 12.5 | 16 | |
| Power Source | 1 Phase 220v, 60Hz | |||||||
| Power Consumption | Cooling | kW | 0.05 | 0.07 | 0.1 | 0.13 | ||
| Heating | 0.05 | 0.07 | 0.1 | 0.13 | ||||
| Sound Power Level | dB(A) | 60 | 62 | --- | ||||
| Sound Pressure Level | dB(A) | Hi: 38 Me: 31 Lo: 26 | Hi: 38 Me: 36 Lo: 31 | Hi: 38 Me: 36 Lo: 31 | Hi: 39 Me: 37 Lo: 32 | Hi: 42 Me: 38 Lo: 34 | Hi: 43 Me: 40 Lo: 35 | |
| Exterior Dimensions H x W x D | mm | 210x1070x690 | 210x1320x690 | 250x1620x690 | ||||
| Net Weight | kg | 28 | 33 | 43 | ||||
| Air Flow | Hi: 10 Me: 7 Lo: 5.5 | Hi: 10 Me: 9 Lo: 7 | Hi: 15 Me: 13 Lo: 10 | Hi: 25 Me: 21 Lo: 16.5 | Hi: 26 Me: 23 Lo: 17 | |||
| Outside Air Intake | Not Possible | |||||||
| Air Filter, Qty | Pocket Plastic net x 2 (Washable) | |||||||
| Remote Control (option) | wired: RC-EX3, RC-E5, RCH-E3 wireless: RCN-E-E2 | |||||||
| Refrigerant Piping Size | Liquid Line: ?6.35 (1/4") Gas Line: ?12.7 (1/2") | Liquid Line: ?9.52 (3/8") Gas Line: ?15.88 (5/8") |
