Aplicaciones Comerciales
VRFs de Mitsubishi Heavy Industries son para usos comerciales.
Especificaciones
| Item | Unit | FDUT15KXE6F-E | FDUT22KXE6F-E | FDUT28KXE6F-E | FDUT36KXE6F-E | FDUT45KXE6F-E | FDUT56KXE6F-E | FDUT71KXE6F-E | |
|---|---|---|---|---|---|---|---|---|---|
| Nominal Cooling Capacity | kW | 1.5 | 2.2 | 2.8 | 3.6 | 4.5 | 5.6 | 7.1 | |
| Nominal Cooling Capacity | kW | 1.7 | 2.5 | 3.2 | 4 | 5 | 6 | 8 | |
| Power Source | 1 Phase 220V, 60Hz | ||||||||
| Power Consumption | Cooling | kW | 0.06 | 0.07 | 0.09 | 0.08 | |||
| Heating | 0.06 | 0.08 | 0.09 | 0.07 | |||||
| Sound Power Level | dB(A) | 52 | 57 | 58 | 59 | ||||
| Sound Pressure Level (1) | dB(A) | Hi: 28 Me: 26 Lo: 22 | Hi: 28 Me: 26 Lo: 22 | Hi: 33 Me: 30 Lo: 26 | Hi: 34 Me: 32 Lo: 28 | Hi: 35 Me: 33 Lo: 30 | Hi: 35 Me: 31 Lo: 28 | ||
| Sound Pressure Level (2) | dB(A) | Hi: 32 Me: 29 Lo: 25 | Hi: 32 Me: 29 Lo: 26 | Hi: 37 Me: 34 Lo: 28 | Hi: 36 Me: 33 Lo: 27 | Hi: 38 Me: 33 Lo: 29 | Hi: 41 Me: 37 Lo: 32 | ||
| Exterior Dimensions H x W x D | mm | 200x750x500 | 200x950x500 | 220x1150x565 | |||||
| Net Weight | kg | 21 | 22 | 25| | 31 | ||||
| Air Flow | m3/min | Hi: 6 Me: 5 Lo: 4 | Hi: 7.5 Me: 6 Lo: 5 | Hi: 8.5 Me: 7 Lo: 5.5 | Hi: 11.5 Me: 9 Lo: 7 | Hi: 12.5 Me: 9 Lo: 7.2 | Hi: 16 Me: 13 Lo: 9.5 | ||
| External Static Pressure | Pa | Standard: 10 Max: 35 | Standard: 10 Max: 50 | ||||||
| Outside Air Intake | Possible from Return Duct | ||||||||
| Air Filter | Filter kit: UM-FL1EF/UM-FL2EF/UM-FL3EF (option) | ||||||||
| Remote Control (option) | wired: RC-EX3, RC-E5, RCH-E3 wireless: RCN-KIT4-E2 | ||||||||
| Refrigerant Piping Size | mm (in) | Liquid Line: ?6.35 (1/4") Gas Line: ?9.52 (3/8") | Liquid Line: ?6.35 (1/4") Gas Line: ?12.7 (1/2") | Liquid Line: ?9.52 (3/8") Gas Line: ?15.88 (5/8") |
