Aplicaciones Comerciales
VRFs de Mitsubishi Heavy Industries son para usos comerciales.
Especificaciones
| Item | Unit | FDUH22KXE6F | FDUH28KXE6F | FDUH36KXE6F | |
|---|---|---|---|---|---|
| Nominal Cooling Capacity | kW | 2.2 | 2.8 | 3.6 | |
| Nominal Cooling Capacity | kW | 2.5 | 3.2 | 4 | |
| Power Source | 1 Phase 220V, 60Hz | ||||
| Power Consumption | Cooling | kW | 0.07 | ||
| Heating | 0.07 | ||||
| Sound Power Level | dB(A) | 60 | |||
| Sound Pressure Level | dB(A) | Hi: 33 Me: 30 Lo: 27 | |||
| Exterior Dimensions HxWxD | mm | 257x570x530 | |||
| Net Weight | kg | 22 | |||
| Air Flow | m3 / min | Hi: 7 Me: 6.5 Lo: 6 | |||
| External Static Pressure | Pa | 30 | |||
| Air Filter | Filter kit: UH-FL1E (option) | ||||
| Remote Control (option) | wired: RC-EX3, RC-E5, RCH-E3 wireless: RCN-KIT4-E2 | ||||
| Refrigerant Piping Size | mm(in) | Liquid Line: ?6.35 (1/4") Gas Line: ?9.52 (3/8") | Liquid Line: ?6.35 (1/4") Gas Line: ?12.7 (1/2") |
