Aplicaciones Comerciales
VRFs de Mitsubishi Heavy Industries son para usos comerciales.
Especificaciones
| Item | Unit | FDUM22KXE6F | FDUM28KXE6F | FDUM36KXE6F | FDUM45KXE6F | FDUM56KXE6F | FDUM71KXE6F | FDUM90KXE6F | FDUM112KXE6F | FDUM140KXE6F | FDUM160KXE6F | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Cooling Capacity | kW | 2.2 | 2.8 | 3.6 | 4.5 | 5.6 | 7.1 | 9 | 11.2 | 14 | 16 | |
| Nominal Heating Capacity | kW | 2.5 | 3.2 | 4 | 5 | 6.3 | 8 | 10 | 12.5 | 16 | 18 | |
| Power Source | 1 Phase 220V, 60Hz | |||||||||||
| Power Consumption | Cooling | kW | 0.1 | 0.2 | 0.29 | 0.33 | 0.45 | |||||
| Heating | 0.1 | 0.2 | 0.29 | 0.33 | 0.45 | |||||||
| Sound Power Level | dB(A) | 60 | 65 | ? | ||||||||
| Sound Pressure Level | dB(A) | Hi: 32 Me: 29 Lo: 26 | Hi: 33 Me: 29 Lo: 25 | Hi: 38 Me: 36 Lo: 30 | Hi: 40 Me: 34 Lo: 29 | Hi: 40 Me: 35 Lo: 30 | ||||||
| Exterior Dimensions H x W x D | mm | 280x750x635 | 280x950x635 | 280x1370x740 | ||||||||
| Net Weight | kg | 29 | 34 | 54 | ||||||||
| Air Flow | m3/min | Hi: 10 Me: 9 Lo: 8 | Hi: 19 Me: 15 Lo: 10 | Hi: 28 Me: 25 Lo: 19 | Hi: 32 Me: 26 Lo: 20 | Hi: 35 Me: 28 Lo: 22 | ||||||
| Maximum External Static Pressure | Pa | 100 | ||||||||||
| Outside Air Intake | Possible | |||||||||||
| Air Filter | Filter kit: UM-FL1EF/UM-FL2EF/UM-FL3EF (option) | |||||||||||
| Remote Control (option) | wired: RC-EX3, RC-E5, RCH-E3 wireless: RCN-KIT4-E2 | |||||||||||
| Refrigerant Piping Size | mm (in) | Liquid Line: ?6.35 (1/4?) Gas Line: ?9.52 (3/8?) | Liquid Line: ?6.35 (1/4?) Gas Line: ?12.7 (1/2?) | Liquid Line: ?9.52 (3/8?) Gas Line: ?15.88 (5/8?) |
